- Процессор AMD EPYC серии 7003, поддерж. до 64-ядер/ 128-потоков
- Поддерж. NVIDIA RTX A6000 / A4500 с тепловыделением
- Рабочая температура от -25 ° C до 60° C
- 2x10G Ethernet от Intel X550-AT 2 и 4xGbE от Intel I350-AM4
- Поддерживает 4 DDR4 RDIMM/ LRDIMM объемом до 512 ГБ
- Компактный корпус 2U 19" для монтажа в стойку глубиной 350 мм
- 4 2,5-дюймовых лотка SATA для 7-мм жестких дисков / SSD
- Широкополосный вход постоянного тока напряжением 8 ~ 48 В
|
System | CPU | Intel ® Baytrail-D Celeron J1900 , 2.0~2.42GHz, 4cores, 4threads, 2M cache, 22nm, TDP 10W |
| System Memory | 1*DDR3L 1333MHz SODIMM, Up to 8GB | |
| Expansion | 1*Full size Mini PCIe(PCIe+USB)with SIM slot, support 4G LTE /Wifi/BT etc.； 1*Full size Mini PCIe(SATA3+USB), used to be mSATA | |
| Graphics | Intel HD Graphics VGA resolution 1920 *1200@60Hz, HDMI resolution1920*1080@60Hz, Dual independent display , Support OpenGL 3.2, DirectX 11, OpenCL 1.2, MPGE2/H.264 | |
| Audio | Realtek ALC662 HD Audio, support 5.1 sound channel, Aduio line out | |
| LAN | 2*Intel I211AT PCIe Gigabit Ethernet, Integrated 10/100/1000M transceiver | |
| KB&MS | USB keyboard and mouse | |
| Storage | 1*2.5" HDD bay, SATA2 3.0Gbps; 1*mSATA full size, dual AHCI | |
| DIO
I/O ports | 8-bit TTL signal, Programmable input and output 2*RJ45 Gig-LAN with LED(Front), 1*USB3.0 Type A (Front); 3*USB2.0 Type A(Front) 1*DB9 connector 8-bit DIO (Rear) 2*RS232/422/485 DB9 male(Rear) 1*HDMI+1*VGA(Front), 1*Audio-out, 3.5mm phone jack(Rear) 1*2pin terminal connector, with power sw signal(Rear) | |
| LED | 1*Power LED, 1*HDD LED, 3*CPU term. LED（Red is warning , Yellow is high, Green is normal) | |
| Control SW | 1*Power button(Front), 1*2pin ter. power-on signal(Rear), 1*AT/ATX Select dip(Front) | |
| Power Supply | DC 9~36V Input, D-Jack with M8 screw (Front), Consumption: TBD 12/1.2A(2.5" HDD) | |
| Watchdog Timer | Watchdog timeout programmable via software 1 to 255 second | |
| OS Support | Windows 7, Windows 8.1, Windows 10, Linux Fedora Ubuntu
|
